Semi-Solid Cell Formation and Aging Protocol
I am Karl Huang, Senior lithium battery Engineer at Horizon Power. Over the past three years I have supervised formation and aging trials for more than forty semi-solid cell batches, from pilot-line pouches to prismatic A-samples bound for commercial packs. If you are building a semi-solid cell formation and aging protocol, the short answer is this: treat formation as a slow, temperature-controlled first-life event, and treat aging as a measured, fully logged degradation study that runs on a fixed calendar and cycle schedule. Semi-solid cells behave differently from conventional liquid-electrolyte cells because the semi-solid electrolyte is a higher-viscosity slurry, so ion transport at the interface is slower and both the formation window and the aging rate shift. In this guide I walk through the exact sequence, the voltage and temperature windows, and the acceptance criteria I use on the line.
What Formation Means for Semi-Solid Cells
Formation is the first controlled charge and discharge that builds a stable solid electrolyte interphase on the anode and conditions the cathode surface. For a liquid lithium cell this step is well understood, but a semi-solid cell adds a complication: the semi-solid electrolyte has higher ionic viscosity and a less mobile interface layer. If you push the first charge too fast, lithium ions cannot cross the interface quickly enough and you get localized plating instead of clean intercalation. That leaves irreversible capacity loss that no later cycle recovers.
In my lab I always treat formation as a low-rate, multi-step event. The goal is a uniform interphase across the full electrode area, not a fast top-up. A well-formed semi-solid cell typically shows capacity grading within two percent of design, while a rushed formation can cost five to eight percent of first-cycle efficiency that the pack designer never gets back.
The Formation Cycle Sequence I Use
Every batch runs the same sequence so the data stays comparable. I log each step in the manufacturing execution system with voltage, current, temperature, and elapsed time.
- Pre-formation open-circuit check: confirm resting voltage between 2.50 and 2.70 volts and run a one kilohertz impedance screen to catch shorts.
- Trickle charge at 0.02C to 2.80 volts to wet the semi-solid interface without stress.
- Constant-current formation at 0.10C to the upper cutoff, followed by a constant-voltage tail at 0.02C held four to eight hours.
- Rest two hours at room temperature, then record open-circuit voltage.
- First discharge at 0.10C to 2.50 volts to measure delivered formation capacity.
- Second formation charge at 0.20C to the upper cutoff with a shorter constant-voltage tail.
- Capacity grading and resistance sorting before the cell moves to aging.
This two-pass approach costs more line time than a single fast formation, but it halves the spread between best and worst cells in a batch, which pays back in pack yield.
Voltage and Temperature Windows During Formation
The upper cutoff depends on the cathode chemistry. For a nickel-rich semi-solid blend I hold 3.90 to 4.00 volts, while an LFP-based semi-solid holds closer to 3.65 volts. I never exceed these ceilings during formation because the semi-solid interface is sensitive to over-potential.
Temperature is the other lever. I run formation at 23 to 25 degrees Celsius with plus or minus one degree control. Higher temperature lowers electrolyte viscosity and improves wetting, but it also raises gas evolution and risks soft swelling. Lower temperature reduces gas but raises the chance of lithium plating. All formation steps stay inside our UN38.3 and IEC 62133-2 safety envelope, and any cell that vents or exceeds 45 degrees Celsius is quarantined on the spot.
Why Aging Protocol Matters
Aging is where the real commercial risk lives. Formation tells you if the cell was made correctly; aging tells you how long it will last in the field. Semi-solid cells age differently from liquid cells. There is less electrolyte dry-out because the semi-solid retains its ionic medium, but interface growth at the anode still dominates long-term fade. If you skip a structured aging protocol you cannot state a warranty, cannot predict state of health, and cannot qualify the cell for second-life use.
For Horizon Power customers I always couple formation records with aging records so a returned cell can be traced back to its exact formation batch. That traceability has saved more than one design iteration.
Calendar and Cycle Aging Tests
I run two parallel tracks. Calendar aging stores finished cells at 50 to 80 percent state of charge inside a 45 or 60 degrees Celsius chamber for four to twelve weeks, with capacity measured every month. This exposes the slow chemical drift that a pack sees while parked.
Cycle aging runs continuous charge and discharge, typically one cycle per one coulomb rate at 25 degrees Celsius to 80 percent depth of discharge. Every one hundred cycles I pause for a reference performance test at 0.20C, recording capacity and electrochemical impedance spectroscopy from one kilohertz down to 0.10 hertz. The impedance rise at low frequency is the earliest signal of interface growth, often visible long before capacity drops below the warranty line.
Acceptance Criteria and Data Logging
A semi-solid cell leaves formation only if it meets these limits: formation capacity at or above 98 percent of design, internal resistance rise below 20 percent after 500 cycles, and no measurable swelling above 3 percent thickness. I reject any cell whose calendar aging loses more than 10 percent capacity in the first twelve weeks at 60 degrees Celsius.
Every data point feeds a single batch record. I keep voltage, current, temperature, time, and impedance for the full life of the test. For stationary and mobility products we align the final report with IEC 62619 and UL 1973, and transport samples still clear UN38.3 before they leave the building. A custom battery solution is only as good as the data behind it, and formation plus aging is where that data is born.
Frequently Asked Questions
How long does semi-solid cell formation take?
A full two-pass formation sequence runs roughly 36 to 48 hours per batch including rest and grading, longer than a liquid cell because the semi-solid interface needs slow constant-voltage soaking to stabilize.
What temperature is best for formation?
I recommend 23 to 25 degrees Celsius with tight control. This balances electrolyte wetting against gas evolution and lithium plating risk, and it keeps the cell inside the UN38.3 and IEC 62133-2 safety envelope.
How is aging different from liquid lithium cells?
Semi-solid cells show less electrolyte dry-out but more interface growth at the anode. That shifts the dominant fade mechanism, so the aging protocol must weight low-frequency impedance tracking more heavily than a liquid cell would.
Can formation be done at a higher C-rate?
Not for first formation. A 0.10C first pass is the fastest I trust; pushing harder risks plating and irreversible capacity loss. The second pass can rise to 0.20C once the interphase is set.
When should a cell be rejected during aging?
Reject on formation capacity below 98 percent of design, internal resistance rise above 20 percent after 500 cycles, swelling beyond 3 percent, or more than 10 percent calendar capacity loss in twelve weeks at 60 degrees Celsius.
Conclusion
A reliable semi-solid cell formation and aging protocol is built on slow, logged formation and disciplined, two-track aging. Hold the voltage and temperature windows, capture every data point, and let the acceptance criteria decide what ships. If you are scaling a new chemistry and need a documented protocol matched to your cell format, the Horizon Power engineering team can build a custom battery solution around your formation and aging targets.
